External dimensions: L 820 x B 680/720 x H 1715 mm
Int. dimensions: L 755 x B 620/660 x H 1500 mm
Weight: 41,5 kg
Volume: 0,702 m³
Maximum load: 500 kg
Bottom1 blue or red plastic pallet 820 x 680 mm, insides reinforced with 4 metal strips. Your name or logo can be hot-stamped in white to short sides. Supplied with two Ø 100 or 125 mm fixed castor wheels and two swivel castors with polyamide, polyurethane or vulcanised rubber tread.
Sides2 demountable sides size 800x1500 mm and 1 back wall, made of Ø 19 mm tube and 2x2 strips 25 x 3 mm. The back wall is equipped with two clamps to clamp the back wall onto the sides. On the front 1 half drop gate of Ø 19 mm tube.
Note boardOn each side wall a blank note board is attached. The note board can be supplied with your name or logo embossed or punched in letters.
Nested and loaded use:Number inside a 13.6 meter truck· Stacked: 270 pieces· Loaded: 60/54 pieces
Castor wheel setThe roll container is mounted on two fixed wheels and two swivel wheels Ø 100 mm or Ø 125 mm, supplied with polyamide, polyurethane or vulcanised rubber tread.
FinishAll steel parts are galvanised.
